DIGITAL DRIVE THRU QLED MENU BOARDS

DIGITAL DRIVE THRU QLED MENU BOARDS

Features

QLED with Fantastic 105% Color Gamut
QLED technology makes the Digital Drive Thru Menu Board full of visual impact. It has an extra 30% brightness creating a full 105% color gamut on the display. The Digital Drive Thru QLED Menu Board leads this trend.

Wide Temperature Range
Wide temperature design on LCD panels, motherboards and stainless steel enclosures makes the display work for 24/7/365 under hot or cold weather.

Sunlight Readable

With brightness reaching up to 4000 nits, the Digital Drive Thru QLED Menu Board is readable under direct sunlight, which delivers clear and attractive content for viewers no matter where they are.

Anti-Glare Glass

The Digital Drive Thru QLED Menu Board is fully laminated with anti-reflection glass, which eliminates the air between the LCD panel and tempered glass. This helps to provide high brightness, lower reflection and high contrast ratio display with 178/178 wide viewing angle, making the displayed images richer and clearer under direct sunlight.

Weatherproof: IP67 Rated

Digital Drive Thru QLED menu Boards are rated IP67, which means the menu board structure provides superior protection against the damaging effects of dust, direct sunlight, rain and snow.

Vandalism Safe
Covered with *IK10-rated impact resistant 4mm thickness tempered glass, the Digital Drive Thru QLED displays are guaranteed for outdoor applications to endure external impacts. *IK rating refers to the degree of resistance against external impacts on a scale of 0 to 10, where 10 indicates the highest level of protection.

Optical Bonding Processed & Reflection Prevention

The Digital Drive Thru QLED Menu Board is fully laminated with anti-reflection glass which eliminates the air between the LCD panel and tempered glass. This helps to provide a high brightness, lower reflection and high contrast ratio display with 178/178 viewing angle.

Non Blackening Feature
Even under direct exposure to sunlight, the display resists blackening defects up to 230°F / 110°C.

Update Over the Internet
Updating your Digital Drive Thru QLED Menu Board is extremely simple; connect it to your network using the integrated Wi-Fi or using an Ethernet cable. Log in to our online content management system to upload your own media, manage playlists, create your own templates and schedule content for whenever you want; giving you complete control over your screens. No special software installation or dedicated PC is required, you can update your screens from anywhere in the world with an internet connection.

POS Integration: Menu Board Sync and Integrated Order Confirmation System

Modernize the drive thru experience and increase transaction speed with Reddie’s Menu Board Sync and Integrated Drive Thru Order Confirmation System. Menu Board Sync allows you to update your  menu board items and prices in real time through your POS. Reddie’s Menu Board Sync integrates with over 50 established POS systems including Square, Clover, Toast, Revel, SpotOn. See list below.

With several of these POS systems our Integrated Drive Thru Order Confirmation System allows customers to view their order cart while an order is being placed which makes for less errors and faster processing of orders.

1 Year Free Software License
With our package the first year of using our cloud-based content management system is absolutely free. You don’t pay anything for 12 months and get full unrestricted access to the software as well as lifetime technical support. You can also make a one-off payment to have access for life. Read more about our non POS integrated software at www.reddieportal.com

Plug and Play (Optional)
The Digital Drive Thru QLED Menu Board comes with an HD Android media player, allowing you to update it using a USB memory stick. Load your pictures and videos onto a USB memory stick then insert it into the display, which will copy the files into its internal flash memory. Once you remove the memory stick the screen will then start playing the pictures and videos in a continuous loop. A USB memory stick can be used as an alternative if you do not want to use our cloud-based software.

Contact Us

Gallery

Case Study

Background

PJ’s Coffee decided to modernize its operations by implementing digital menus to enhance customer experience and streamline menu updates. This shift to digital menus was aimed at providing a dynamic and engaging interface for their customers, allowing for easy updates to menu items, prices, and promotions.

The Problem

The vendor recommended initially by the franchise for supplying and installing these digital menus presented a significant challenge. Upon receiving the detailed proposal and cost breakdown, it became evident that the vendors services were prohibitively expensive.

These unforeseen expenses posed a substantial financial burden, especially for smaller franchise locations operating on tighter budgets. The high cost made it difficult to justify the investment, potentially delaying the rollout of the digital menus. This situation necessitated a search for more cost-effective alternatives that could provide the desired technological upgrade without compromising the financial stability of the franchise.

Solution & Benefits

Reddie stepped in to offer affordable solutions tailored to PJ’s Coffee’s needs:

1. Digital Drive Thru QLED Menu Boards: Reddie’s Digital Drive Thru QLED Menu Boards offered an efficient and durable solution designed to withstand various weather conditions. These boards improved order accuracy and reduced wait times, enhancing overall customer satisfaction.

2. Commercial Menu Boards: Reddie provided cost-effective, all-in-one commercial menu boards that enhanced the customer experience with visually appealing and interactive displays. These dynamic boards allowed for easy and real-time updates to menu items, prices, and promotions.

By choosing Reddie, PJ’s Coffee was able to implement a modern and efficient digital menu system that their customers love and also met their budgetary constraints. Reddie’s cost-effective solutions facilitated the rollout of digital menus at their location, ensuring enhanced customer experiences and operational efficiency without compromising financial stability.

Build Your Own Drive Thru

Industry Standard Drive Thru Communication Systems Available.

Our communication systems include headsets, vehicle detectors, loops, base stations, speaker post, speaker, microphone and order confirmation system.

National Recognised Testing Laboratory (NRTL)

Our Digital Drive Thru Menu Board meets the NRTL standards making it on par with top level and best in class industry standards.

Contact Us

Technical Details

Panel Information

Panel size: 43”
Resolution: 1080×1920
Brightness: 4000 nits
Active Area: 941x605mm
Viewing Angle (L/R/U/D): 89/89/89/89
Aspect Ratio: 16:9
Display Colors: 1.07B, 105%
LED Lifetime:  50,000 hours
Blackening Defect Free: Up to 110 °C / 230 °F
Orientation: Portrait & Landscape

Mechanical

Brightness Control: Sensor Built-in
Bezel Width (T/B/L/R): 28/28/28/28 mm | 1/1/1/1 inch
Overall Dimensions: 999*588*125 mm | 40*24*5 inches
Net Weight (Display Only): 28 kg / 61 lbs

Connectivity

HDMI IN x 1
Power Port x1
OSD Language: English
Operating System: Optional Reddie Media Player
Operating System: Optional Built-In OS (Android 11/Windows 10)

Special Features

Tempered Glass: Anti-Reflective Glass with IK10 Impact-resistant
Process: Optical Bonded
Weatherproof Design: IP66
Cooling System: Smart Cooling Fan
Operating Temperature: -20°C ~ 60°C / -4°F ~ 140 °F

Power

Power Supply: AC 110~240V
Rated Frequency: 50/60Hz

Panel Information

Panel size:49”
Resolution: 1080×1920
Brightness: 4000 nits
Active Area: 1075x6050mm
Viewing Angle (L/R/U/D): 89/89/89/89
Aspect Ratio: 16:9
Display Colors: 1.07B, 105%
LED Lifetime:  50,000 hours
Blackening Defect Free: Up to 110 °C / 230 °F
Orientation: Portrait & Landscape

Mechanical

Brightness Control: Sensor Built-in
Bezel Width (T/B/L/R): 26/26/26/26 mm | 1/1/1/1 inch
Overall Dimensions: 1127*657*119 mm | 45*26*5 inches
Net Weight (Display Only): 33 kg / 73 lbs

Connectivity

HDMI IN x 1
Power Port x1
OSD Language: English
Operating System: Optional Reddie Media Player
Operating System: Optional Built-In OS (Android 11/Windows 10)

Special Features

Tempered Glass: Anti-Reflective Glass with IK10 Impact-resistant
Process: Optical Bonded
Weatherproof Design: IP66
Cooling System: Smart Cooling Fan
Operating Temperature: -20°C ~ 60°C / -4°F ~ 140 °F

Power

Power Supply: AC 110~240V
Rated Frequency: 50/60Hz

Panel Information

Panel size:55”
Resolution: 1080×1920
Brightness: 4000 nits
Active Area: 1210x680mm
Viewing Angle (L/R/U/D): 89/89/89/89
Aspect Ratio: 16:9
Display Colors: 1.07B, 105%
LED Lifetime:  50,000 hours
Blackening Defect Free: Up to 110 °C / 230 °F
Orientation: Portrait & Landscape

Mechanical

Brightness Control: Sensor Built-in
Bezel Width (T/B/L/R): 28/28/28/28 mm | 1/1/1/1 inch
Overall Dimensions: 1262*733*85 mm | 50*29*4 inches
Net Weight (Display Only): 37 kg / 82 lbs

Connectivity

HDMI IN x 1
Power Port x1
OSD Language: English
Operating System: Optional Reddie Media Player
Operating System: Optional Built-In OS (Android 11/Windows 10)

Special Features

Tempered Glass: Anti-Reflective Glass with IK10 Impact-resistant
Process: Optical Bonded
Weatherproof Design: IP66
Cooling System: Smart Cooling Fan
Operating Temperature: -20°C ~ 60°C / -4°F ~ 140 °F

Power

Power Supply: AC 110~240V
Rated Frequency: 50/60Hz
